Vectorizing Time with Time2Vec

Introduction

Machine Learning models can only understand data that can be encoded in a numerical form.

Real Numbers such as Distances, Mass, Population, etc. can be simply normalized and fed to a Machine Learning Algorithm. Here’s a list of “type” of Data and most “standard” way of encoding them (pun intended).

But things aren’t so straight forward for some type of data.

For example, how would you encode a Date? Traditionally, only features extracted from Dates have been used, such as “Weekend/Weekday”, “Season”, “Quarter” etc, as one would notice, that this would lead to a lot of information loss, how do we encapsulate the entire information in a given date?

Consider a date 2021-01-12, Should we normalize across Year, Month, and Day as separate features? or One-Hot encode them? Why is this a bad idea?

• Periodicity of Days, Months, and Years is not captured by neural nets with non-periodic activation functions (Most neural nets).
• Exploding/Vanishing Gradients due to growing inputs.

Time2Vec

The Time2Vec “Layer” is defined as:

Where,

• \(\cal F\) is a periodic function for e.g. \(Sine(\sdot)\) or \(Cosine(\sdot)\)
• \(w_i, \varphi_{i}\) are learnable parameters

Points to Note:

• \(k-1\) components learn periodic features, \(1 \le i \le k\).
• One component allows learning of Non-periodic features, \(i = 0\).

Link to the Paper: “Time2Vec: Learning a Vector Representation of Time”

Time2Vec - Code

We’ll use PyTorrch with my open-source implementation of Time2Vec here

PyTorch implementation

import torch
from torch import nn
import numpy as np
import math

def t2v(tau, f, out_features, w, b, w0, b0):
    # k-1 periodic features
    v1 = f(torch.matmul(tau, w) + b)
    # One Non-periodic feature
    v2 = torch.matmul(tau, w0) + b0
    return torch.cat([v1, v2], 1)

class SineActivation(nn.Module):
    def __init__(self, in_features, out_features):
        super(SineActivation, self).__init__()
        self.out_features = out_features
        self.w0 = nn.parameter.Parameter(torch.randn(in_features, 1))
        self.b0 = nn.parameter.Parameter(torch.randn(in_features, 1))
        self.w = nn.parameter.Parameter(torch.randn(in_features, out_features-1))
        self.b = nn.parameter.Parameter(torch.randn(in_features, out_features-1))
        self.f = torch.sin

    def forward(self, tau):
        return t2v(tau, self.f, self.out_features, self.w, self.b, self.w0, self.b0)

I think the code is self-explanatory.

I have also provided a pretrained model to encode Date-Time in ISO format (e.g. 13:23:30 2019-7-23) to a vector of 64 dimensions. The pretraining task is “Next Date Prediction”, a dataset of pairs of date-time and their immediate next date-time is generated and trained in a supervised fashion. After training, the decoder is discarded, and it can be now used to generate embeddings for date-time.

A sample code for getting embedding from this Date2Vec package is shown below.

from Model import Date2VecConvert
import torch

# Date2Vec embedder object
# Loads a pretrained model
d2v = Date2VecConvert(model_path="./d2v_model/d2v_98291_17.169918439404636.pth")

# Date-Time is 13:23:30 2019-7-23
x = torch.Tensor([[13, 23, 30, 2019, 7, 23]]).float()

# Get embeddings
embed = d2v(x)

print(embed, embed.shape)

Conclusion

We talked about an incredibly simple technique that allows Neural Nets to understand periodic features.
